TripLine Safety

TripLine Safety
TripLine is a new safety product specifically designed for use on the front of performance stages. The system provides a discreet visual and physical barrier to the front line of the stage for both performers and stage crew.
The Tripline system provides a clear visual indication of the stage edge even in complete show blackout situations by means of a line of LED's positioned 30cm apart.This visual front line also has a failsafe backup in the application of a photoluminus strip which will glow in the dark for up to 8 hours without the need for an electrical power supply.

Made from Aluminium box sections (25mm x 50mm) and available 1m, 2m and 3m lengths, the units can be mounted along the front line of a stage to provide a physical barrier in order to stop flightcases, stage trucks and tallescopes from rolling over and into the auditorium or pit areas. It can be fitted temporarily or permanently which makes it ideal for touring or for ever changing venues.

The top and rear of the TripLine unit can be specified in a number of different finishes to provide high grip, high visibility, photoluminescent or a discreet finish so that an audience is completely unaware that the Tripline unit is even in operation.The colour of the LED's can be configured for multiple uses either to demarcate separate areas of the stage to help in choreography to ensure dancers hit their marks or they can line up on an unlit stage evenly. By using green LEDs you could simply show access points or stairways beyond the TripLine.

LM TL-L100-3RED

1.0m TripLine with 3 LEDs – Red



LM TL-L200-6RED

2.0m TripLine with 6 LEDs – Red

LM TL-L300-9RED

3.0m TripLine with 9 LEDs – Red
